10/100/t to 100fx adecomm media converter industrial series, singlemode stand alone 20km, sc connector, din rail mount, 12?48vdc dual power input

Descripción

10/100/t to 100fx adecomm media converter industrial series, singlemode stand alone 20km, sc connector, din rail mount, 12?48vdc dual power input
the adecomm industrial media converter provides one port 100m fiber and one port 10/100m utp, it?s applicable to use in desktop fast ethernet networking. it is designed with ip175/icplus chip to ensure stability and ultra-low time-delay data transmission. built-in led indicators for pwr, 100, sd, fdx link/act, fx, tx can dynamic feedback link connection state and fault detection to easily monitor network status.
features:
*fiber port: sc, 100mbps. singlemode fiber tyoe, up to 20km.
*utp port: rj-45 10/100mbps, with auto negotiation function can auto select 10/100m and full duplex or half duplex, supports the connection of mdi/mdi-x auto crossover
*led indicators: pwr, fdx, fiber, tp, link, 100m
*utp/stp cable: cat.5 or cat.5e up to 100m
*standard compliance: ieee 802.3u, 100base-tx
*support flow control and broadcast storm protection
*supporting the max 1552 byte ethernet packet and flow control
*vlan function is customized
*mac address table: 2k support self-learning update
*data buffer: 384kb
*power supply: dc 5v-1a
*ip40, din-rail /wall mount.
*operating temperature range: -40°c ~ +85°c
*storage temp.(?): -40°c ~ +85°c
*size (l*w*h): 115 *85*30 ?mm?
